| MODEL NO. | D±2 | L±2 | H±2 | M (UNC) |
M1 (UNC) |
T | W | LOAD (KGF) |
| KC-1265S-60-12-60 | 60 | 60 | 25 | 12 | 6 | 3 | 19 | 1800 |
| KC-1265S-60-12-100 | 60 | 100 | 25 | 12 | 6 | 3 | 19 | 1800 |
| KC-1265S-80-12-60 | 80 | 60 | 27 | 12 | 6 | 3 | 19 | 1700 |
| KC-1265S-80-12-100 | 80 | 100 | 27 | 12 | 6 | 3 | 19 | 1700 |
| KC-1265S-80-16-70 | 80 | 70 | 29 | 16 | 6 | 3 | 24 | 2200 |
| KC-1265S-80-16-100 | 80 | 100 | 29 | 16 | 6 | 3 | 24 | 2200 |
| KC-1265S-80-20-100 | 80 | 100 | 31 | 20 | 6 | 3 | 30 | 2200 |
| KC-1265S-80-20-150 | 80 | 150 | 31 | 20 | 6 |
